MAYTAG WASHER MHW5630HW Won T Fill
| CONF | DIAGNOSIS | ACTION |
|---|---|---|
|
86%
CONF
|
Water Inlet Valve Assembly
This component contains the solenoids that electronically open to allow water into the dispenser. In this model, the coils can fail electrically (no continuity) or the internal diaphragm can become jammed with sediment, preventing water flow despite receiving power from the control board.
SKU: W11210462
|
|
|
9%
CONF
|
Door Latch and Lock Assembly
Front-load washers will not initiate the fill cycle unless the door is physically locked and the lock switch provides feedback to the main control board. If the wax motor or solenoid inside the latch fails, the cycle is halted immediately, resulting in a machine that appears powered on but refuses to fill.
|
|
|
5%
CONF
|
Water Level Pressure Sensor
This sensor monitors air pressure in a tube to determine water depth. If the sensor is out of calibration or the hose is pinched/clogged, the control board may receive a 'full' signal even when the tub is empty, preventing the inlet valves from ever opening.
|
DIY Repair Guide
Watch exactly how to replace the Water Inlet Valve Assembly.
