SAMSUNG DW80R5060US Error Leak Catch
| CONF | DIAGNOSIS | PART MATCH | ACTION |
|---|---|---|---|
|
91%
CONF
|
Leak Sensor
This sensor is the component that generates the LC signal. It is located at the lowest point of the base pan and is susceptible to false positives from condensation or residue even if a major leak is not present. Replacing the sensor or the sensor bracket ensures the control board receives accurate moisture data.
|
|
|
|
5%
CONF
|
Case Brake (Water Guide) Assembly
The Case Brake manages the water intake and air gap functions. In this model series, the assembly often develops internal blockages or seal failures at the gasket interface, causing a slow drip into the base pan during the fill cycle which eventually triggers the leak sensor.
SKU: DD82-01341A
|
|
|
|
4%
CONF
|
Drain Pump
The drain pump utilizes a mechanical shaft seal to prevent wash water from entering the motor housing. Over time, friction and debris can degrade this seal, allowing small amounts of water to escape into the bottom tray during the drain phase, leading to a latent LC error.
SKU: DD31-00015A
|
|
DIY Repair Guide
Watch exactly how to replace the Leak Sensor.
