KENMORE 106 SERIES COLDSPOT Leaking From Freezer
| CONF | DIAGNOSIS | ACTION |
|---|---|---|
|
93%
CONF
|
Defrost Drain Link / Heat Probe
This component is a copper strap that attaches to the defrost heater and extends into the drain hole. It solves the root cause by conducting heat into the drain port during the defrost cycle, preventing the melt-water from refreezing and creating an ice dam. Without this thermal bridge, liquid water hits the cold plastic of the drain trough and solidifies, eventually causing the trough to overflow into the freezer cabin.
|
|
|
4%
CONF
|
Replacement Defrost Drain Tube
The original drain tube often features a 'duckbill' valve at the termination point which is prone to sticking shut due to biological growth or dust accumulation. This mechanical blockage prevents condensate from exiting the system, causing it to back up into the freezer. Replacing the tube ensures a clear volumetric path for the fluid dynamics of the defrost cycle.
SKU: W10619951
|
|
|
3%
CONF
|
Bi-Metal Defrost Thermostat
While the presence of liquid water suggests the heater is turning on, a failing bi-metal thermostat can terminate the defrost cycle prematurely. This leaves behind a 'slush' that quickly refreezes at the drain entrance. Replacing this ensures the timing of the thermal application is sufficient to allow all melt-water to exit the cabinet.
SKU: W10225581
|
DIY Repair Guide
Watch exactly how to replace the Defrost Drain Link / Heat Probe.
